Robust Air
Cooling Technology
Robust Water
Cooling Technology
Check out our detailed Hash Generator™ 90 kW walkthrough
SPECS - Air Cooled Hash Generator™
| Hash Generator 50 kW AC | Hash Generator 80 kW AC | Hash Generator 160 kW AC |
Hash Generator 325 kW AC
|
|
| Building Dimension (WxLxH) | 5x14x9.5 | 6x16x9.5 | 10x18x9.5 | 10x28x10.5 |
| Prime Power Rating (kW) | 65 | 113 | 229 | 392 |
| Continuous Power Rating (kW) | 48 | 80 | 160 | 325 |
| EPA certified engine | No | Yes | ||
| Fuel Type | Natural Gas / Propane | |||
| Estimated fuel consumption (MCF/d) | 12 | 24 | 50 | 91 |
| Electrical Input | 3-phase, 416Y240VAC (default) / 480Y277VAC, 60 Hz | |||
| Switchgear Rating (A) | 150 | 250 | 400 | 800 |
| AC Rack Quantity | 1 | 1 | 2 | 4 |
| Miner Slots | 12 | 24 | 48 | 96 |
| Miner Compatibility | M30, M50, M60, S19, S21, S21+, S21 Pro, S21 XP | |||
| Total Rated CFM | 8,000 | 20,500 | 41,000 | 82,000 |
| VFD (HP) | N/A (single speed) | 10 | 10 | 25 |
| Download Specs | Download Specs | |||
HASH GENERATORS
Hundreds of Hash Generators all over North America
In 2017 we introduced the world to conserving vented and flared natural gas via bitcoin mining and have constantly improved our modular Hash Generator™ product line ever since.
Get a Quote
We optimize power generation in both the utility power industry and the oil and gas sector.
